Description
DESCRIPTION
61″ Velocity Plus™ Cutter Deck, 38 HP Kohler® Command PRO® EFI – electronic fuel injection
FEATURES
- The envy of the neighborhood – 48″, 52″ or 61″ Cutting Width: The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge on 48″, 52″ and 61″ widths. An Advantage Cutter Deck is featured on 32″ and 36″ widths.
- Adjustable Operator Platform – Experience an Unmatched, Ultra-Comfortable Ride: The spacious operator platform delivers a smooth ride and reduces operator fatigue. Adjustable suspension spring can be moved forward or backward, with, or without, the spacer plate installed to meet the operator’s comfort preference. Extra-large, extra-thick operator comfort cushion ensures comfortable operation, hour after hour.
- Cutter-Deck Lift System – Convenient, Spring-Assisted Lever: Cutter deck can be lifted and locked into transport position from the operator’s station. Cutting heights are easily set by placing the tethered pin at the desired height.
- Ogura PTO Clutch Brake – Strong, Adjustable Clutch for Long Life: Provides excellent starting and stopping power for the cutter deck and an adjustable air gap for long life.
- High-Strength Steel Frame – Solid Design for Years of Dependable Service: Heavy-duty, single-tube, steel main-frame construction delivers superior strength and ensures years of trouble-free service. The front caster-wheel weldments are replaceable.
SPECIFICATIONS
- : 61″ Velocity Plus™ Cutter Deck, 38 HP Kohler® Command PRO® EFI – electronic fuel injection
- Total Fuel Capacity: 5 gallons (32″); 6.75 gallons (36″); 8 gallons (48″, 52″, and 61″)
- Drive Tires: 20″ x 6.5″-10″ (32″); 20″ x 8″-10″ (36″); 24″ x 9.5″-12″ (48″ and 52″); 24″ x 12″-12″ (61″)
- Caster Tires: 11″ x 4″-5″ (32″ and 36″); 13″ x 5″-6″ (48″ and 52″); 13″ x 6.5″-6″ (61″)
- Seat: Extra-large comfort cushion
- Drive System Type: Dual Pump and Motor
- Pumps: Hydro-Gear 10 cc (32″ and 36″); Hydro-Gear 12 cc (48″, 52″, and 61″)
- Motors: Parker 12 ci (32″ and 36″); Parker 14 ci (48″, 52″ and 61″)
- Forward Ground Speed: 8.5 mph (32″ and 36″); 10.5 mph (48″, 52″ and 61″)
- Reverse Ground Speed: 5 mph
- Parking Brake: Hand lever
- Cutting Widths: 32″, 36″, 48″, 52″ and 61″
- Type: Advantage (32″ and 36″); Velocity Plus™ (48″, 52″, and 61″)
- Cutting Height: 1.5″ to 4.5″ in .25″ increments
- Deck Lift: Hand lever
- Construction: Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles.; 32″ model features dual-plate.
- Spindles: Cast-iron housing with tapered roller bearings.
- Blade Engagement: Ogura GT2.5 (150 ft lb) – (32″, 36″, 48″ and 52″); Ogura GT3.5 (250 ft lb) – (61″); Adjustable air-gap for extended life.
DIMENSIONS
- Length: 72.75″
- Tracking Width: 48″
- Width (chute down): 73.5″
- Width (chute in transport position): 62.75″
- Height: 47.25″
- Weight: 1,127-1,173 lb
ACCESSORIES
- 2-Bag V-Ride II Spindle Driven Grass Catcher
- Fabric Bag Grass Catcher
- Hurricane Plus™ Mulch System
- Hurricane Mulch System
- Mulch Plate
- OCDC – Operator-Controlled Discharge Chute
- Light Kit
- Chrome Wheel Covers
- Air Filter Monitor
- Blade Buddy
- 12-Volt Accessory Outlet
