Description
When you’re dealing with hydraulic cylinders or remote valves on your tractor, having the right hose assembly makes all the difference. This 44-inch hydraulic hose combines a 90-degree ORB fitting on one end with a straight NPT fitting on the other—perfect for those tight spaces where you need to make connections without fighting the routing. It’s designed to handle the hydraulic flow and pressure your equipment demands while giving you the flexibility to connect different components.
What You’re Getting
- 3/8 inch diameter with 1-wire construction for reliable medium-pressure applications
- 44-inch length gives you the reach you need for most tractor hydraulic connections
- 90-degree ORB (O-Ring Boss) fitting on one end eliminates the need for additional elbow fittings
- Straight 1/2 inch NPT fitting on the other end threads directly into standard hydraulic blocks
- Single wire braiding provides good flexibility while maintaining pressure ratings
Built for Real Farm Work
This hose assembly is ideal for connecting hydraulic cylinders on loaders, three-point hitches, and remote hydraulic outlets on tractors and equipment. The mixed fitting configuration—ORB to NPT—is common in agricultural applications where you’re connecting modern hydraulic components to older hydraulic blocks or valves. Whether you’re running a bush hog, operating a grapple, or cycling lift cylinders, this hose handles the job.
Made to Last
Sutter Bros. is confident in their ability to build custom hydraulic hoses to exact specifications and guarantees the product will be free of defects. The single-wire construction provides good durability for medium-pressure hydraulic systems while staying flexible enough to route around obstacles and moving parts on your equipment.
Installation Notes
The ORB fitting uses an O-ring seal, so make sure the O-ring is in good shape and the sealing surface is clean before installation. The NPT fitting should be threaded in with pipe thread sealant or Teflon tape for a leak-free connection. Keep in mind that this is a direct replacement assembly—just match up your fitting types and you’re ready to go.
